DB9000 Series

Product Code:
Availability: In Stock

$0.00

Qty

Apple and Android Compatible
BLE (Bluetooth Low Energy) Management
Optional Gateway Connectivity (Remote Management Through The Internet)
Proximity RFID Card (13.56 Mhz) Standard
Digital Touchscreen
Timestamped Access Log (Audit Trail)
1 Admin Phone, 49 Client Phones Per Deadbolt
50 Digital Combinations Per Deadbolt
50 RFID Cards / Key Fobs Per Deadbolt
10,000 Audit Trail Entries
1 Admin Phone Can Manage Up To 250 Deadbolts
Emergency Key Override
RFID Key Fob (Optional)
Individual User Access Mode
Optional Auto Re-Locking
Door Jam Protector
Smart L / R Handing Learning
Key / Thumb-Turn Turning Detector
One-Tap Locking
Weather Resistant
Buzzer & Led Indicators
Anti-Tamper Lockout
Low Battery Warning
Emergency Charge Interface
1 Year Electronic Warranty

APPLICATIONS For residential and standard duty commercial applications.
DOOR RANGES 1 ⅜” to 1 ¾” thickness
BACKSET Adjustable 2 ⅜” (60mm) or 2 ¾” (70mm)
LATCH FACEPLATE 2 ¼” x 1”.
PROXIMITY CARD (STANDARD) 2 pcs. included. Compatible with existing MIFARE Infrastructure. Operates at 13.56 MHz in accordance with ISO 14443A. Inductive distance up to 1 3/16”.
RFID KEY FOB (OPTIONAL) Operates at 13.56 MHz in accordance with ISO 14443A. Inductive distance up to 1 3/16”.
POWER SUPPLY 4 AA 1.5V Alkaline Batteries (comes standard in packing).
RADIO FREQUENCY Bluetooth radio frequency: 2.4 GHz
CYLINDER & KEYWAYS 6 pin solid brass “C” keyway standard. Schlage E, Schlage C-K, Russwin D1-2-3-4, Corbin 59 / 60, Corbin-Russwin L4, Sargent LA-LB-LC, Falcon / Weiser E, Arrow A, Yale 8, Yale GA and Kwikset. Can also accept Medeco, Assa, Kaba and Cal-Royal (HSK) High Security Cylinders.
WEATHER RESISTANT All models are weather resistant for operating temperature ranges of +158○F to -4○F (+70○C to -20○C) and storage temperature ranges of +176○F to -22○F (+80○C to -30○C).
BLUETOOTH CONNECTIVITY Lock can be managed / synced using the K3 (Apple) and K3+ (Android) app.
ACCESS LOG (AUDIT TRAIL) The K3 app features a 24 / 7 activity log, so you can keep track which client accessed the lock. A timestamped access log can be shared by the Admin phone via email. 10,000 audit trail entries.
STRIKE Deadbolt strike 1 ⅛” x 2 ¾”. Optional strikes available.
OPTIONAL GATEWAY CONNECTIVITY Optional BLE Gateway connectivity for remote lock management.
