Cal-Royal Products, Inc.

CRPS1N

The CRPS1N is a heavy duty, high quality, low cost solution for powering a single latch retracting exit device. The solid-state design insures years of trouble-free operation. The power supply delivers raw, unregulated DC current which is ideal for the extreme in-rush requirement of most motor driven electric latch retracting exit devices. The power supply comes housed in a sturdy, yet compact metal enclosure.

• Power supply delivers the necessary high current in-rush for a single exit device
• Solid-state design eliminates problems associated with mechanical relays
• Single input/output

CRPS220/CRPS220B

The CRPS220 and CRPS220B (Battery Backup) are regulated, linear power supplies rated at 2 Amps @ 24V DC to (2) PTC fused outputs. It also provides (2) solid-state input triggers, protects system relays from shorts, grounds and surges. These power supplies may also be used to power electrified mortise and cylindrical locks, electric strikes, mag locks, motorized exit devices.

• Built to run up to 2 locks, exit trim, and LP Motor / Solenoid kits
• Two independent inputs / outputs
• Linear design insures ample inrush / hold current for latch retraction
• Door mounted LED Power Indicator
• Fire alarm link
• Removable Euro-style terminal blocks allow for easy installation
• No hassle 3-year warranty

  Additional Features (CRPS220B Only):

• Regulated, independent battery charging
• Automatic uninterrupted backup circuit
• Battery cables included
• Requires (2) 12V DC 7AH batteries
• Batteries not included

CRSW3

The CRSW3 is a low cost, regulated switching power supply. It is designed specifically to supply power to low current DC devices such as mortise locks, cylindrical locks, electric strikes, and any type of access control systems. The CRSW3 supplies an auto volt input 100-260V AC. The unit is housed in a light weight and high-quality lockable metal enclosure.

• Short Circuit, Overheating and Over Voltage Protection
• Can be run with multiple devices as long as it does not exceed capacity
• Fire Alarm Link Compatible
• No hassle 3-Year Warranty

Additional Features (Battery Backup):

• Regulated, independent battery charging
• Automatic uninterrupted backup circuit
• Battery Overdischard Protection
• Battery cables included
• Requires (2) 12V DC 7AH batteries
• Batteries not included

CRPS440B/CRPS480B

The CRPS440B and CRPS480B (Battery Backup) are regulated, linear power supplies rated at 4 Amps @ 24V DC to (4) or (8) PTC fused outputs. It also provides (4) or (8) solid-state input triggers, protects system relays from shorts, grounds and surges. These power supplies may also be used to power electrified mortise and cylindrical locks, electric strikes, mag locks, motorized exit devices.

• Adjustable output voltage from 24-27VDC
• Built to run up to 4 or 8 locks, exit trim, and LP Motor / Solenoid kits
• 4 or 8 independent inputs / outputs
• Linear design insures ample inrush / hold current for latch retraction
• Door mounted LED Power Indicator
• Fire alarm link
• Removable Euro-style terminal blocks allow for easy installation
• No hassle 3-year warranty

Additional Features (Battery Backup):

• Regulated, independent battery charging
• Automatic uninterrupted backup circuit
• Battery cables included
• Requires (2) 12V DC 7AH batteries
• Batteries not included

CRPS1N

• Input voltage – 120V AC, 60 Hz, 2 Amp Input Fuse
• Output voltage – 24V DC  @ 1A
• Temperature range – 0 to 120F
• 1 Solid-State input / output (input triggered by dry contact)
• LEDs
  • RED = A/C Power indicator
  • GREEN = D/C Output Indicator
• Enclosure dimensions: 11” x 11” x 4”

CRPS220/CRPS220BB

• Input Voltage – 120V AC, 60 Hz, 2 Amp Input Fuse
• Output Voltage – 24V DC @ 2A
• 2 Solid-State input / output (input triggered by dry contact)
• LEDs
  • RED = A/C Power indicator
  • GREEN = D/C Output Indicator
• Enclosure dimensions:
  • 11” x 11” x 4” (CRPS220)
  • 13" x 15.5" x 5" (CRPS220B)

CRSW3

• Input voltage – 100-260V AC, 60 Hz
• Output voltage – 5A @ 24V DC
• with Independent Switching Relay
• Enclosure dimensions : 9” x 11” x 3”

CRPS440B/CRPS480B

• Input Voltage – 120V AC, 60 Hz, 2 Amp Input Fuse
• Output Voltage – 24V DC @ 4A
• CRPS440B: 4 Solid-State Input / Output (input triggered by dry contact)
• CRPS480B: 8 Solid-State Input / Output (input triggered by dry contact)
• Power Tap -  24V DC @ .5A
• LED’s:
  • RED = A/C Power indicator
  • GREEN = D/C Output indicator
  • ORANGE = Battery Output Indicator
• Enclosure dimensions : 13” x 15.5” x 5”

[Download File]

Power Supplies for Electrified Exit Devices
